JLG 2030ES – 20′ Electric Scissor Lift

Specifications

• Platform Height (elevated): 20'
• Working Height: 26'
• Platform Capacity: 800 lbs
• Capacity on Platform Extension: 250 lbs
• Lift / Lower TIme: 28 / 40 seconds
• Maximum Drive Height: Fully Elevated
• Weight: 3,610 lbs
• Ground Bearing Pressure: 81 psi
• Drive Speed (elevated): 0.5 mph
• Drive Speed (lowered): 2.75 mph
• Turning Radius (inside): Zero
• Turning Radius (outside): 81"
• Power Source: 4 x 6v, 220 amp-hr
• Charger: 20 amp Automatic
• Drive: 24v Electric
• Hydraulic Capacity: 1.25 gallons
• Platform Height (lowered): 43.5"
• Platform Railing Height: 43.3"
• Overall Height (rails lowered): 5' 11.5"
• Platform Size: 30" x 90.5"
• Platform Extension: 35.5"
• Overall Width: 30"
• Overall Length: 7' 6.5"
• Wheelbase: 6' 2"
• Ground Clearance: 3.5"
